Portable handheld oscilloscope for daily debug and test

For those seeking the convenience of a portable oscilloscope, the 2 Series MSO delivers unmatched performance. It's small enough to fit into a laptop bag but offers robust specifications, including bandwidths up to 500 MHz and a maximum sample rate of 2.5 GS/s, with options for 2 or 4 analog channels. The front and side I/O ports provide easy access and connectivity. Additionally, the optional detachable battery pack offers versatility for bench or field use.

Simple touchscreen interface and controls

The 2 Series MSO offers the same award-winning touchscreen user interface and simplified control panel you’ve come to expect on the most advanced Tektronix oscilloscopes.

Simplified front panel with only the most critical controls

Colored LED ring lights around the knobs indicate active sources or parameters to adjust

Colored LED light under buttons indicate status

Comprehensive debug with one instrument

With several integrated options, the 2 Series MSO is equipped for all your debugging needs in just one instrument.

Built-in 16 MSO channels for testing digital circuits (2-MSO instrument option)

Analyze the frequency response of a system with the built-in Bode plot feature (2-SOURCE software option)

50 MHz AFG, 4-bit pattern generator for simulating the circuit under test (2-SOURCE software option)

Supports a variety of probes to capture a wide range of signals

Comprehensive Analysis for Fast Insight

• A full suite of analysis tools provides immediate access to instrument configuration or waveform management tasks with a single tap.

• Waveform and screen-based cursors with user-selectable readout location

• Unlimited automated measurements

• Basic and advanced waveform math including arbitrary equation editing

• FFT for spectrum analysis

Optional accessories add versatility

Two-slot battery pack supports up to eight hours of battery life and can be hot swapped in the field

Rack mount kit attaches easily to VESA mount and allows access to all instrument ports

Optional protective case safeguards instrument from drops up to 40 inches and includes kickstand and carrying bag

Compatible with many off-the-shelf VESA accessories, including a rolling cart, cup holder mount, desk arm mount, and more

Analyze, share, collaborate with oscilloscope software

Capture data outside the lab, classroom, or any location and collaborate easily with colleagues on the next bench or in the next time-zone.

Built-in VNC server to control instrument from devices such as PC, tablet, or phone

TekDrive cloud storage facilitates record-keeping and collaboration

Analyze data on or off the scope with TekScope™ PC analysis software that works just like the scope

TekScope and TekDrive offered for six months free

Kickstart Software enables multi-instrument control, data collection and analysis
