Kyoritsu MODEL 3005A DIGITAL INSULATION / CONTINUITY TESTER
Brand :
Kyoritsu
Categories :
Insulation Tester
• Displays the value of external AC voltage along with flashing symbol.
• Auto null function to automatically subtract the test lead resistance before displaying the real continuity resistance value.
• Live circuit warning beeper.
• Releasing the test button automatically discharges the charges stored in the circuit under test.
• 200mA continuity measuring current to IEC 61557.
• Minimum 1mA current on insulation tests to IEC 61557.
Specifications
-
Accuracy
±1.5%rdg±5dgt (20MΩ/200MΩ) ±10%rdg±3dgt (2000MΩ)
-
Test voltage
250V/500V/1000V
-
Nominal current
1mA DC min.
-
Output short circuit current
1.5 mA DC approx.
-
Output voltage on open circuit
Rated test voltage+20%, -0%
-
Measuring ranges<br>(Mid-scale value)
20MΩ/200MΩ/2000MΩ
-
Accuracy
±1.5%rdg±5dgt (20Ω) ±1.5%rdg±3dgt (200Ω/2000Ω)
-
Measuring current
200mA DC min.
-
Output voltage on open circuit
7 - 12V DC
-
Measuring ranges<br>(Mid-scale value)
20Ω/200Ω/2000Ω
-
Accuracy
±5%rdg±3dgt
-
AC voltage range
0 - 600V AC
-
Weight
970g approx
-
Dimension
167(L) × 185(W) × 89(D)mm
-
IP Rating
IEC 60529-IP54
-
EMC Standard
IEC 61326-1
-
Power source
R6 (AA) (1.5V) × 8
-
Safety Standard
IEC 61010-1 CAT III 300V Pollution Degree 2 IEC 61010-2-031 IEC 61557-1/2/4
-
Included Accessories
7122B (Test leads) Pouch for test leads 8923 (F500mA/600V fuse) × 2 R6 (AA) × 8, Shoulder Strap Instruction Manual
