Home/Brands/ Cirrus Research/Class 1 & Class 2 Acoustic Calibrators

Cirrus Class 1 & Class 2 Acoustic Calibrators

Brand : Cirrus Research
Categories : Class 1 & Class 2 Acoustic Calibrators

  • IEC 60942: 2017 Class 2 & Class 1 Performance
  • PTB Type Approval for CR: 514 and CR:515 Class 2 & Class 1 acoustic calibrators
  • LNE Type Approval for CR:515 Class 1 acoustic calibrator
  • 94dB sound pressure level output for CR:514 and CR:515 Class 1 and Class 2 acoustic calibrators
  • Dual-level 94dB and 114dB sound pressure level outputs for CR:516 and CR:517 Class 1 and Class 2 acoustic calibrators
  • Suitable for use with standard 1/2" microphone capsules
  • 1/4" Microphone adaptor available
  • Automatic power switch off with user override giving longer battery life
  • Robust case with ergonomic design


GET QUOTE

Specifications

Class 1 and Class 2 Sound Calibrators with Type Approvals

Cirrus Research manufactures a range of acoustic calibrators (often referred to as sound calibrators) and adaptors suitable for the field calibration of sound level meters, noise dosimeters and other noise measurement instruments.

Our current range of acoustic calibrators comprises:

  • CR:514 Class 1 Sound Calibrator to IEC 60942:2003 Class 2 with PTB Type Approval and 94dB @ 1kHz sound pressure level output

  • CR:515 Class 1 Sound Calibrator to IEC 60942:2003 Class 1 with PTB and LNE Type Approval and 94dB @ 1kHz sound pressure level output

  • CR:516 Class 2 Sound Calibrator to IEC 60942:2017 Class 2 with 94dB & 114dB @ 1kHz sound pressure level output

  • CR:517 Class 1 Sound Calibrator to IEC 60942:2017 Class 1 with 94dB & 114dB @ 1kHz sound pressure level output

CR:514 Class 2 & CR:515 Class 1 Sound Calibrators

The CR:514 and CR:515 are high-performance acoustic calibrators designed for the field and laboratory calibration of sound level meters and other noise measurement equipment.

The units are simple to operate and meet the requirements of the latest IEC 60942:2003 standard for acoustic calibrators with performance to Class 2 (CR:514) and Class 1 (CR:515).

The CR:515 and CR:514 are the standard acoustic calibrators that are supplied with Cirrus Research sound level meters and noise meausrement instruments.

CR:516 Class 2 & CR:517 Class 1 Dual-Level Sound Calibrators

The CR:516 and CR:517 acoustic calibrators are designed to meet the requirements of IEC 60942: 2017 and provide both 94dB and 114dB at 1kHz in one instrument.

The CR:516 and CR:517 acoustic calibrators can be used to calibrate both sound level meters and noise dosimeters and feature sound pressure level outputs of 94dB and 114dB at 1kHz.
